Gray electrically insulating sidewalk

available 8 variants
Configure the product using the filters to make a purchase.
Ask for product Catalog card
Product Mpn Thickness [mm] Width [mm] Length [mm] Price
gross

Chodnik elektroizolacyjny Szary CHESZ1000 5 1200 1000 On request
Chodnik elektroizolacyjny Szary CHESZ2000 5 1200 2000 On request
Chodnik elektroizolacyjny Szary CHESZ3000 5 1200 3000 On request
Chodnik elektroizolacyjny Szary CHESZ4000 5 1200 4000 On request
Chodnik elektroizolacyjny Szary CHESZ5000 5 1200 5000 On request
Chodnik elektroizolacyjny Szary CHESZ6000 5 1200 6000 On request
Chodnik elektroizolacyjny Szary CHESZ7000 5 1200 7000 On request
Chodnik elektroizolacyjny Szary CHESZ8000 5 1200 8000 On request

Gray Insulating Walkway



The insulating walkway is a specialized mat that protects against electric shock in high-voltage areas. Made of dielectric material, it effectively isolates and protects users. It has anti-slip properties, is resistant to oils and chemicals. Used in switchgear rooms, power plants, and workshops.



Insulating Walkway - available dimensions



Width: 1220 ± 25 mm

Length: 1.0 ÷ 8.0 m

Thickness: 5 ± 0.5 mm



Color: gray



Class 2 Insulating Walkway - technical specification

Class 2 Insulating Walkway is a certified personal protection element used when handling electrical equipment. It provides effective insulation against electrical hazards, increasing the safety of workers in high-voltage areas.



Technical Specification:

  • Standard: PN-IEC 61111:2002/A1:2004
  • Voltage test: Each roll undergoes a voltage test with an AC test voltage of 20 kV.
  • Voltage resistance: The effective value of the withstand AC voltage is minimum 30 kV.



Resistance to external factors:

  • Acid resistance: According to standard PN-IEC 61111 - test in H₂SO₄ 23°C / 8h.
  • Oil resistance: Test conducted in oil no. 1, 70°C / 24h.
  • Low temperature resistance: Test according to standard PN-IEC 61111 at -25°C / 1h.



Each walkway is supplied with a protocol from the voltage test, ensuring its high quality and compliance with safety standards.

Product designed for use in electrical switchgear rooms, power plants, transformer stations, and workshops, where there is a risk of contact with high voltage.
